Sapphire Scientific

460 Truckmount

Options
  • 72-570 - 90 gal. / 341 L waste tank
  • 72-570HC - 120 gal. / 454 L waste tank
  • Product Details

    The 570 delivers phenomenal heat and vacuum with the durability of the Kubota three-cylinder liquid-cooled power plant. The 570's patented thermal well system uses a finned tube coil design and full thermostatic control for optimal heat delivery all day. The 570 is the best choice for extended durability and maximum performance.

  • Specifications
    • Power plant: Kubota WG972 31 HP liquid cooled cast iron gasoline engine operating at 3000 RPM
    • Vacuum pump: Gardner Denver HeliFlow<sup>®</sup>& Twisted Tri-Lobe HF408 positive displacement blower. Vacuum at 13 in. and flows up to 455 CFM.
    • Solution pump: General HTS2016S producing up to 1500 PSI and 5 GPM at 1500 RPM
    • Belt cooling: 100 CFM through-frame air injection system
    • Console dimensions (W×H×D):
      • 22 × 43 × 50 in.
      • 56 × 109 × 127 cm
    • Frame construction: 0.125 in. × 2 in. powder-coated aluminum box tubing.
    • Belt cooling: 100 CFM through-frame air injection system
    • Legend Rewards: 15,000 points
    View Full Specs
